Theme Documentation - echarts Shortcode

2020-03-03 1012 words 5 minutes views

The echarts shortcode supports data visualization in Hugo with ECharts library.

ECharts is a library helping you to generate interactive data visualization.

The basic chart types ECharts supports include line series , bar series , scatter series , pie charts , candle-stick series , boxplot series for statistics, map series , heatmap series , lines series for directional information, graph series for relationships, treemap series , sunburst series , parallel series for multi-dimensional data, funnel series , gauge series . And it’s extremely easy to create a combinition of them with ECharts.

Just insert your ECharts option in JSON/YAML/TOML format in the echarts shortcode and that’s it.

Example echarts input in JSON format:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
{{< echarts >}}
{
  "title": {
    "text": "Summary Line Chart",
    "top": "2%",
    "left": "center"
  },
  "tooltip": {
    "trigger": "axis"
  },
  "legend": {
    "data": ["Email Marketing", "Affiliate Advertising", "Video Advertising", "Direct View", "Search Engine"],
    "top": "10%"
  },
  "grid": {
    "left": "5%",
    "right": "5%",
    "bottom": "5%",
    "top": "20%",
    "containLabel": true
  },
  "toolbox": {
    "feature": {
      "saveAsImage": {
        "title": "Save as Image"
      }
    }
  },
  "xAxis": {
    "type": "category",
    "boundaryGap": false,
    "data": ["Monday", "Tuesday", "Wednesday", "Thursday", "Friday", "Saturday", "Sunday"]
  },
  "yAxis": {
    "type": "value"
  },
  "series": [
    {
      "name": "Email Marketing",
      "type": "line",
      "stack": "Total",
      "data": [120, 132, 101, 134, 90, 230, 210]
    },
    {
      "name": "Affiliate Advertising",
      "type": "line",
      "stack": "Total",
      "data": [220, 182, 191, 234, 290, 330, 310]
    },
    {
      "name": "Video Advertising",
      "type": "line",
      "stack": "Total",
      "data": [150, 232, 201, 154, 190, 330, 410]
    },
    {
      "name": "Direct View",
      "type": "line",
      "stack": "Total",
      "data": [320, 332, 301, 334, 390, 330, 320]
    },
    {
      "name": "Search Engine",
      "type": "line",
      "stack": "Total",
      "data": [820, 932, 901, 934, 1290, 1330, 1320]
    }
  ]
}
{{< /echarts >}}

The same in YAML format:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
{{< echarts >}}
title:
    text: Summary Line Chart
    top: 2%
    left: center
tooltip:
    trigger: axis
legend:
    data:
        - Email Marketing
        - Affiliate Advertising
        - Video Advertising
        - Direct View
        - Search Engine
    top: 10%
grid:
    left: 5%
    right: 5%
    bottom: 5%
    top: 20%
    containLabel: true
toolbox:
    feature:
        saveAsImage:
            title: Save as Image
xAxis:
    type: category
    boundaryGap: false
    data:
        - Monday
        - Tuesday
        - Wednesday
        - Thursday
        - Friday
        - Saturday
        - Sunday
yAxis:
    type: value
series:
    - name: Email Marketing
      type: line
      stack: Total
      data:
          - 120
          - 132
          - 101
          - 134
          - 90
          - 230
          - 210
    - name: Affiliate Advertising
      type: line
      stack: Total
      data:
          - 220
          - 182
          - 191
          - 234
          - 290
          - 330
          - 310
    - name: Video Advertising
      type: line
      stack: Total
      data:
          - 150
          - 232
          - 201
          - 154
          - 190
          - 330
          - 410
    - name: Direct View
      type: line
      stack: Total
      data:
          - 320
          - 332
          - 301
          - 334
          - 390
          - 330
          - 320
    - name: Search Engine
      type: line
      stack: Total
      data:
          - 820
          - 932
          - 901
          - 934
          - 1290
          - 1330
          - 1320
{{< /echarts >}}

The same in TOML format:

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
{{< echarts >}}
[title]
text = "Summary Line Chart"
top = "2%"
left = "center"

[tooltip]
trigger = "axis"

[legend]
data = [
  "Email Marketing",
  "Affiliate Advertising",
  "Video Advertising",
  "Direct View",
  "Search Engine"
]
top = "10%"

[grid]
left = "5%"
right = "5%"
bottom = "5%"
top = "20%"
containLabel = true

[toolbox]
[toolbox.feature]
[toolbox.feature.saveAsImage]
title = "Save as Image"

[xAxis]
type = "category"
boundaryGap = false
data = [
  "Monday",
  "Tuesday",
  "Wednesday",
  "Thursday",
  "Friday",
  "Saturday",
  "Sunday"
]

[yAxis]
type = "value"

[[series]]
name = "Email Marketing"
type = "line"
stack = "Total"
data = [
  120.0,
  132.0,
  101.0,
  134.0,
  90.0,
  230.0,
  210.0
]

[[series]]
name = "Affiliate Advertising"
type = "line"
stack = "Total"
data = [
  220.0,
  182.0,
  191.0,
  234.0,
  290.0,
  330.0,
  310.0
]

[[series]]
name = "Video Advertising"
type = "line"
stack = "Total"
data = [
  150.0,
  232.0,
  201.0,
  154.0,
  190.0,
  330.0,
  410.0
]

[[series]]
name = "Direct View"
type = "line"
stack = "Total"
data = [
  320.0,
  332.0,
  301.0,
  334.0,
  390.0,
  330.0,
  320.0
]

[[series]]
name = "Search Engine"
type = "line"
stack = "Total"
data = [
  820.0,
  932.0,
  901.0,
  934.0,
  1290.0,
  1330.0,
  1320.0
]
{{< /echarts >}}

The rendered output looks like this:

The echarts shortcode has also the following named parameters:

width [optional] (first positional parameter)
Width of the data visualization, default value is 100%.
height [optional] (second positional parameter)
Height of the data visualization, default value is 30rem.
